機器型號/Model

DSL3200

打印技術/Print Technology

Piezo continuous drop-on demand(DOD)

噴頭類型/Head Model

RICOH GEN5/RICOH GEN6/KM10241/KM1024A

噴頭控制/Print Head Control

軟件調整噴頭溫度，噴頭電壓/SoftwareAdjustHead temperature& Voltage

噴頭配置/Print head Configuration

KCMYx2/KCMYx3/KCMYLCLmx2/KCMY//KCMYLcLm(白色選配/whiteasoptional)

打印幅寬/Maximum Printing Size

3.20m

打印分辨率/Print Resolution

2880 dpi

最快打印速度/Print speed Upto

150mi/h

墨水類型/INKType

UV型墨水/Environmental friendly UV/LED curable ink

顏色配置/Color Profile

KCMYLcLm(可選/optional)/KCMYLcLmWV(可選/optional)

刮墨裝置/Auto.cleaningsystem

有/Available

供墨方式/Ink Supply system

采用真空負壓自動連續供墨

烘干裝置/Drying System

LED UV燈固化/LED UVlamp curing

包裝尺寸/Package size

6340x1938x2168

機器尺寸/Machine size

5580x1730x1560

機器重量/Machine Weight

2.5噸/2.5Tons

打印接口/PrintingInterface

PCIE系統/PCIE System

電源要求/PowerRequirement

主機/Main frame220V+10%50HZ3300W風機/UV燈220V±10%50HZ5000W

環境要求/Environmental Requirements

溫度/Temperature 15℃~30°℃ 相對濕度/Relative humidity40%~80%

RIP軟件/RIP Software.

Printfactory/Calder
